| Genset Rating | kVA | 60 |
| Genset Model | - | TMTL-60-TP |
| Duty | Prime / Standby | Prime |
| Control Panel | - | Options Available for Manual and AMF |
| Acoustic Insulation Type | - | PU Fire Retardant |
| DG Set Dimensions ( L X B X H) | mm | 2500x1100x1575 |
| Fuel Tank Capacity | L | 125 |
| Dry Weight of DG Set (Approx +/- 25 Kg) | kg | 1375 |
| Engine manufacturer | - | TAFE MOTORS AND TRACTORS LIMITED |
| Engine brand | - | TMTL ENGINES |
| Engine model | - | 333W0-EG060 |
| Number of cylinders | nos. | 3 |
| Aspiration | - | Turbocharged intercooled |
| Engine power (Gross) | BHP | 74.8 |
| Reference standard | - | Engine: As per ISO 3046 -1, Genset: As per ISO 8528 |
| Displacement | cc | 3298 |
| Compression ratio | - | 17.5 + 0.5 : 1 |
| Type of governer | - | Electronic/Isochronous |
| Class of Governing | - | G3 |
| Stroke | mm | 108 |
| Bore | mm | 120 |
| Type of cooling | - | Liquid Cooled |
| Lube oil Sump capacity (with filters) | L | 8 |
| Coolant Capacity - TOTAL | L | 13 |
| Coolant Capacity - Radiator | L | 5 |
| Battery | Volts, Ah | 12 VDC, 99/100 Ah |
| Exhaust After Treatment System | - | EGR + DOC |
| Phase | - | 3 |
| Voltage | VAC | 415 |
| Power Alternator Type | - | Brushless with AVR, Single Bearing, Bell Housing: SAE 3/10 |
| Power Factor | Lag | 0.8 |
| Rated speed & frequency | RPM/Hz | 1500 /50Hz |
| Engine power (Gross) | KW | 55.0 |
| Fuel injection System / FIP Type | - | Bosch CRS (CB18) |
| Air cleaner | - | Dry type |
| Voltage Regulation | % of Rated voltage | +/- 1% |
| Insulation | - | Class-H |
| Make | - | Stamford/ Leroy Somer/ CG/ Meccalte |
| Starting System | - | Electric |
| Battery Make | - | Exide / TATA |
| Silencer Location & Type | - | Internal, Residential |
| Acoustic Insulation Thickness | mm | 40 mm Thick on Body Panels (25 mm thick at Louvers) |
| Dry Weight (Engine) (Approx)+ | kg | 485 |
* Note:
1. For optimal performance of the engine, it is suggested to run the genset / generator at loads in excess of 25%
2. Fuel consumption is with radiator and fan (wherever applicable)
3. Fuel consumption data is based on diesel having specific gravity of 0.85 and conforming to IS:1460. Fuel consumption tolerance is +5%
4. Conformance standards: IS-4722, BS-5000, IS-1460, ISO-8528, BS-5514, ISO-3046
+ Note on weight of the genset:
1. The weight of the genset / generator is approximate
2. Tolerance applicable on the weight of the genset / generator owing to variation in the genset accessories and different makes of the alternator
